Gurus Double Decker 1959

Attribute:

Share

Categories : Gurus Pedal

Share

When we designed the 1959 DD, we always kept in mind the sound we wanted to produce with rich details, harmonics and an organic sound with tons of dynamics: an “in-your-face” tone. We also wanted to create a device which could easily obtain these great tones with effective and intuitive controls.1959 DD required a lot of engineering work to fit the size, despite using the high quality components normally used in amplifiers and with the important consideration of space. To keep the standard pedals power supply (9-12VDC Negative tip), we pushed our Twin Dynamic ™ over the limit, making it able to increase the input voltage many times so as to obtain the maximum dynamic range of the signal. 1959DD is your perfect companion on the stage, both as an “Overdrive warehouse” on your large pedal board, or in a small setup with the effects placed in the loop. It is also great for studio or home use providing your records an excellent starting point for your guitar sound, Simply connecting it to your PC with or without Speaker simulator.

Power 9VDC (Negative Tip)
230 mA

Power 12VDC (Negative Tip)
280 mA

Max Consumption
300 mA

S/N Ratio
58db

Max Gain
98db

Max Boost
8db

Input Impedance
<1M Ohm

Output Impedance
<100M Ohm

Send Impedance
<100M Ohm

Return Impedance
<100M Ohm

D.I.Out Impedance
<47M Ohm

Serial FX Loop
0db

Parallel FX Loop (50%)
0db

Max Return Signal
0,3Vpp

Max D.I.Out Signal
0,1Vpp

Dimensions
220x125x50mm

Others:

FSW 1:
Bypass/Floor 1

FSW 2:
Floor 2/Solo

Series
100% Post EQ Mix

Parallel
50% Post EQ Mix

Direct
No SPK. Sim. +4db

Emulated
SM57 + 2xV30
