HEAVY DUTY custom made anodized aluminium
case in sandblasting /frosted black finish.
WEIGHT: 490 grs (1 lb)
Dimensions: 125 x 105 x 65 mms - 5,2x 3,9x2.5 inches
Power supply requirements:
Voltage: 9 to 12V DC regulated
Connector: 2.1mm DC jack, Center negative
Current consumption: 200mA
Recommended supply current: 250mA and up
Input Impedance:
Input: 1Meg Ohm L & R return: 1Meg Ohm
Output impedance:
Send: 1K Ohm
Unbalanced Outputs: 4.7K Ohms
Balanced Outputs: 100 Ohms
Headphone amp specs:
Power: 135mW into 32 Ohms.
* Use with 16, 32, 64 and 96 Ohm Headphones.
* Loss of power can occur with higher impedance headphones.
